Description
Parameter:
|
1×N |
||||||
|
Item |
Parameter(P grade) |
|||||
|
Wavelength(nm) |
1260～1650 |
|||||
|
Port |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
|
Max insertion loss(db) |
4.3 |
7.4 |
10.7 |
13.9 |
17.2 |
21.5 |
|
Uniformity(db) |
0.5 |
0.8 |
1.0 |
1.4 |
1.6 |
2.0 |
|
PDL(dB) |
＜0.2 |
＜0.3 |
＜0.3 |
＜0.3 |
＜0.3 |
＜0.5 |
|
Return loss(dB) |
≥50 |
|||||
|
Directivity(dB) |
≥50 |
|||||
|
Operating temperature(℃) |
-20～+75 |
|||||
|
Operating Humidity(%RH) |
≤93 |
|||||
|
2×N |
||||||
|
Item |
Parameter(P grade) |
|||||
|
Wavelength(nm) |
1260～1650 |
|||||
|
Port |
2×2 |
2×4 |
2×8 |
2×16 |
2×32 |
2×64 |
|
Max insertion loss(db) |
4.3 |
7.6 |
11.0 |
14.8 |
17.9 |
21.5 |
|
Uniformity(db) |
0.8 |
1.0 |
1.2 |
1.5 |
1.8 |
2.5 |
|
PDL(dB) |
＜0.2 |
＜0.3 |
＜0.3 |
＜0.3 |
＜0.3 |
＜0.5 |
|
Return loss(dB) |
≥50 |
|||||
|
Directivity(dB) |
≥50 |
|||||
|
Operating temperature(℃) |
-20～+75 |
|||||
|
Operating Humidity(%RH) |
≤93 |
|||||
Size(mm):
|
Package |
1×2 2×2 |
1×4 |
2×4 |
1×8 |
2×8 |
1×16 |
2×16 |
1×32 |
2×32 |
1×64 2×64 |
|
Blokless |
45*4.5*4 60*7*4 |
45*4.5*4 |
60*7*4 |
80*12*4 |
80*20*6 |
90*20*6 |
100*40*6 |
|||
|
ABS box |
90*20*9.5 |
100*80*10 |
100*80*10 120*80*18 |
120*80*18 |
141*115*18 |
|||||
Order information：
|
9C-PS |
Port |
Diameter |
Length |
Fiber |
input connector |
output connector |
|
|
102=1×2 104=1×4 …… 164=1×64 202=2×2 …… 264=2×64 |
09=0.9mm 20=2.0mm 30=3.0mm |
05=0.5M 10=1 M 15=1.5 M 20=2 M X=other |
1＝G652D 2＝G657A |
00=none SU=SC/UPC FU=FC/UPC ST=ST/UPC |
00=none SU=SC/UPC FU=FC/UPC ST=ST/UPC |
